Facebook Open Graph API META Tags

When I was designing Singapore Azure Bootcamp website, I was extremely happy to use HTML5 and CSS3 and the website looked fantastic. But when I shared the website link on Facebook to get more traffic, the Facebook post randomly took one of the pictures I had posted on the website, a description and displayed it. Well of course, that’s not what I wanted. I recently found another tech-event website (masked the event names in the image below) with similar issue so I thought to pen down my learnings on Facebook Open Graph API that provides solution to this problem
Fig1_5204
Facebook’s Open Graph protocol allows for web developers to turn their websites into Facebook “graph” objects that allows us a certain level of customization over how information will be carried over from a non-Facebook website to Facebook when a page is “recommended”, “liked”, or just generally shared. This information is set via the Open Graph Meta tags – tags that are prefixed with og: with the format mentioned below in the HTML head section

<meta property="og:{tagName}" content="{tagValue}"/>

So here are few tweaks I did to get things corrected.

4 Important Meta Tags

Setting the Site Name

The meta tag og:site_name is very handy to provide Facebook some context about your site

<meta property="og:site_name" content="Azure Bootcamp 2015 Singapore Website"/>

Setting the Image

I rescaled the Azure Bootcamp image to 250×250 as its best to use a square image and saved it as fb_img.png (AFAIK, we can also use JPG format) in my assets folder and added a og:image meta tag in the HTML head section. The image META tag directs Facebook to use the specified image when the page is shared

<meta property="og:image" content="http://globalazurebootcampsg.azurewebsites.net/assets/img/fb_img.png">

If we are using CDN resources, we can also mention the image path on CDN

Setting the Title (or Display Name)

The meta tag og:title is used to specify the title of the URL. Generally, it should be the page/article title.

<meta property="og:title" content="Global Azure Bootcamp Singapore - 25th April 2015">

In my case, it represented the Azure Bootcamp 2015 event.

Setting the Link URL

The URL should be the canonical address for the page.

<meta property="og:url" content="http://singapore.azurebootcamp.net">

For the Azure Bootcamp site, we were using Azure hosting so our original website address was http://globalazurebootcampsg.azurewebsites.net (used earlier in the image) however, we wanted everyone to be aware of the routed/public URL http://singapore.azurebootcamp.net

Testing these settings

Once we have added these META tags to the HTML head section of our page/website, we can check the information Facebook receives using the Facebook Lint Tool.

Fig2_5204
When we enter the URL we want to share on the Lint Tool, it uses Open Graph API to retrieve the META tags and provides us a sample of what will be visible when the URL is shared by anyone.

Fig3_5204

Leverage the Lint Tool and Facebook Open Graph API (i.e. META tags) to bring a different and attract few more visitors to your website from Facebook!

Reference: Facebook Open Graph API META Tags from our NCG partner Punit Ganshani at the Punit Ganshani blog blog.
